Arteriovenous haemangioma of the vas deferens: a case report and literature review

Introduction

Haemangioma is a benign tumor characterized by the proliferation of vascular endotheliocytes, and it often involves the head, neck, trunk and limbs (1,2). According to its pathological features, haemangioma can be classified as capillary haemangioma, cavernous haemangioma or arteriovenous haemangioma (1-3). Haemangioma of the vas deferens is an extremely rare entity in clinical practice. To date, there have been no cases reported in Medline, Embase or other published English literature. Herein, we present a case of haemangioma of the vas deferens, in accordance with the CARE and SCARE reporting checklists (available at http://dx.doi.org/10.21037/tau-20-1156).

Case presentation

A 50-year-old male was referred to our hospital with a chief complaint of intermittent right scrotal pain for 4 years after vasectomy. The pain was induced by heavy physical labor or sexual intercourse and could radiate to the right inner thigh, seriously affected his labor ability and quality of life. We reviewed the patient's previous surgery records and found that two 1 cm incisions were made in the scrotum, and the bilateral vas deferens were isolated and excised with a size of approximately 0.6 cm with tissue scissors. The two ends were ligated with silk sutures and cauterized with an electrotome, a procedure that was performed under local infiltration anesthesia in March 2015. Three months ago, a magnetic resonance imaging (MRI) examination in the local hospital showed that the lesion located in the right vas deferens demonstrated inhomogeneous hypointense signals on T1WI, and inhomogeneous iso- and hyperintense signals on T2WI, which was in accordance with inflammatory disease (only the MRI examination report was available). Physical examination revealed old surgical scars in bilateral scrotal lateral walls, and a tender nodule, approximately 0.3 cm × 0.3 cm in size, in the right scrotum, which was demarcated by the right testis and epididymis upon palpation. Given the concern for malignancy, some necessary laboratory tests were conducted. The value of ß-human chorionic gonadotropin (ß-hCG) was 1.8 mU/mL (normal range: 0–3.2 mU/mL for males), of alpha fetoprotein (AFP) was 18.4 µg/L (normal range: less than 25 µg/L), and of lactic acid dehydrogenase (LDH) was 177 U/L (normal range: 135–215 U/L), and the other laboratory tests, such as blood routine examination, urinalysis, and coagulation function tests were normal. Color Doppler ultrasound showed bilateral epididymal tubular ectasia and no other information concerning the tender nodule in the right scrotum was detected (Figure 1). In light of the EAU guidelines on vasectomy and other pertinent literature (4-7), ibuprofen (200 mg, once a day) was administered orally to this patient for 2 months, but pain relief was not obvious. Then, we performed spermatic cord block with lidocaine, dexamethasone and gentamicin, which significantly alleviated the patient’s pain symptoms. After detailed medical consultations and communication, the patient signed an informed consent form and agreed to undergo resection of the painful nodule in the right vas deferens. We made a 2.5 cm incision in the high lateral wall of the right scrotum and isolated the two ends of the vas deferens. The right painful nodule was located at the proximal vas deferens stump and was well circumscribed intraoperatively by a faint yellow capsule with the size of 0.3 cm × 0.4 cm grossly. We isolated this lesion along the yellow capsule and cut it with tissue scissors; then, we ligated the proximal stump again with silk sutures. After resection of the lesion, we still explored the right epididymis and testis and found that the epididymis was mildly swollen. Moreover, the morphology and color of the right testis were normal. Postoperative pathological examinations revealed that the nodule was an arteriovenous haemangioma (Figure 1). There were no obvious complications postoperatively and scrotal pain was relieved significantly 1 month later. All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee(s) and with the Helsinki Declaration (as revised in 2013). Written informed consent was obtained from the patient.

Figure 1 Pathological and imaging examinations of arteriovenous haemangioma of the vas deferens. (A,B,C) The pathological sections of the arteriovenous haemangioma stained by haematoxylin and eosin (HE), magnified 50, 200, and 400 times respectively. (D) The ultrasound revealed no additional information about the painful nodule in the right scrotum.

Discussion

Haemangioma is a benign tumor composed of dilated vessel lumina and relatively thin walls that is common in the dermis of the face, head, trunk and extremities (1-3,8). Although it could theoretically involve any organs in the body (9), haemangioma is a rare entity in the urinary and male reproductive systems. Kryvenko (10) once described 8 cases of haemangioma derived from testes and all lesions in the testes were recognized by ultrasound, so he believed that clinical physical examination and imageological examination could suggest haemangioma preoperatively. Other researchers (1,3,8) have reported that haemangioma in the testes or epididymis is difficult to distinguish from other malignancies due to the rarity and lack of characteristic imaging findings, even though the levels of ß-hCG, AFP, and LDH are within normal limits. Hitherto, this is the first report of haemangioma of the vas deferens in the English literature, which we discovered in a male patient with a history of vasectomy. Preoperatively, considering the history of vasectomy, the near-term MRI examination report, the ultrasonography and the four years of intermittent pain symptom, we speculated that the painful nodule in the right scrotum was spermatic granuloma, which is a common cause in patients with post-vasectomy pain syndrome (PVPS) due to inflammation and sperm leakage from the proximal stump of the vas deferens (6,7,11).Unexpectedly, the post-operative pathological examination revealed that the lesion was an arteriovenous haemangioma.

Although we failed to detect the painful nodule in the vas deferens in our case, conventional color Doppler ultrasound could reveal abundant information about lesions in the genitourinary system, including the position, size, texture, blood signals, and relationships with surrounding structures, preoperatively (12). Interestingly, Frates (13) performed scrotal ultrasound in 345 male patients, and found mobile echogenicities in the epididymis of those who had previously undergone vasectomy. Therefore, he thought mobile echogenicities were probably related to clumps or clusters of spermatozoa. Contrast-enhanced ultrasound (CEUS) is a new imaging method that is widely accepted for its safety and accuracy (14). Yang (15) once succeeded in diagnosing a case of thyroid haemangioma with CEUS preoperatively, and believed that the “slow in and slow out” pattern of contrast filling and perfusion was the characteristic feature of haemangioma. Wu (16) summarized the typical features of liver haemangioma as peripheral nodular and centripetal enhancement during the arterial phase followed by hyper- or isoenhancement during the portal venous and late phases on CEUS. MRI, especially enhanced MRI can also provide valuable diagnostic information for haemangioma before surgery (1-3,17). Intense heterogeneous contrast enhancement was found on T1 weighted images, while T2 weighted images demonstrated hypointensity of this lesion (3). It is believed that the golden criteria of diagnosis of haemangioma is pathological examination. In addition to dilated lumina, thin walls, and vascular endotheliocytes proliferations, immunohistochemistry staining results can further confirm the diagnosis of haemangioma in the genitourinary system, including positive CD31, CD34, FVIII-related protein positivity (3,10)

The 2012 AUA guidelines on vasectomy (18) mentioned that approximately 1–2% of men who underwent vasectomy suffered from severe chronic scrotal pain, currently referred to as PVPS. PVPS was defined as more than 3 months of constant or intermittent scrotal content discomfort or pain, severe enough to interfere with daily activities and prompting patients to seek medical attention (5,19,20). Tandon (6) and Tan (5,19) summarized the possible pathophysiological mechanisms of PVPS as follows: (I) Back pressure increments in an obstructed proximal vas deferens and epididymis, leading to epididymal interstitial fibrosis and scrotal pain. This could perfectly explain the intermittent pain induced by heavy physical labor or sexual intercourse in our case, causing sympathetic nervous excitement and subsequent epididymal and vas deferential smooth muscle contraction. (II) Due to the rupture of epididymal ducts and extravasation of sperm, local inflammation could result in local painful nodules. This is why the resection of sperm granuloma could sometimes alleviate the symptoms of individuals with PVPS; (III) The nerves around the vas deferens or epididymis are densely encased in fibrous tissue, with distortion, angulation and lymphatic infiltration. This is the theoretical basis and feasibility for micro-denervation of the spermatic cord for PVPS management.

In terms of the treatment for PVPS, non-surgical treatment should be the first choice for the management of PVPS (5,6,20,21). If non-surgical treatment failed to control symptoms, patients with PVPS might benefit from surgical therapies, which included resection of nodules or granulomas, vasectomy reversal, spermatic cord denervation, epididymectomy, and orchiectomy (5-7,12,19-22). Tan (5,19,20) emphasized that diagnostic spermatic cord block should be performed prior to surgical therapy and surgeries could be performed only with obvious improvements in pain from spermatic cord block. In this case, we first administered NSAIDs (ibuprofen) to the patient for more than 2 months with frustrating outcomes and then spermatic cord block achieved tentative satisfactory results. Finally, under medical advice, the patient chose resection of the painful nodule which was proven to be arteriovenous haemangioma instead of spermatic granuloma by postoperative pathology. Staggers (23) once reported a capillary haemangioma of the finger in an adult after a burn. Several cerebral cavernous angiomas have been reported in individuals who underwent brain radiotherapy for glioma or other malignancies (24,25). Therefore, we boldly hypothesize that the haemangioma might be associated with thermal injury caused by a burn, radiation or electrotome cauterization. Due to the lack of sufficient haemangioma cases, this hypothesis needs to be proven by basic research or cohort studies in the future.

The objective of this article is to remind urologists and oncologists that haemangiomas could involve in the vas deferens and, an addition to the spermatic granuloma, might be one reason for PVPS. Cauterization of the vas deferens might have a potential relationship with haemangioma.
